Multi Axis CNC Turning and Milling Specialists

Precision Engineering

Here at Doosan, our goal is to exceed our customers’ expectations. We work very closely with our customers, taking into account their priorities and objectives to deliver an exceptional service, by creating quality precision components.

Our Specialisms

Multi Axis CNC Turning

All the turning centres at Doosan are equipped with live tooling to create complex mill/turned components. We utilise the latest Multi Axis machine tools and employ advanced cutting tool technology to achieve this, where possible, in one operation. We have also invested in Lights Out techniques to enable un-manned machining, which helps to reduce costs and lead times.

Request a CNC Turning quote

Our Specialisms

Multi Axis CNC Milling

The VMC (Vertical Machining Centres) at Doosan are equipped with high power 12000 RPM spindles and were chosen for their features and flexibility. They also have generous table sizes and work envelopes. This assists with work-holding and allows us to run multiple vices and/or fixtures for larger components. For those components with complex 3D surfaces, we employ the latest version of OneCNC, with its extensive library of cutting tool strategies for rapid metal removal.

Request a CNC Milling quote

Plant List

Our machinery

We pride ourselves on being skilled technicians, but our job is made easier by using some of the greatest technology available on the market. These are some of our machines.

DOOSAN DNM 400 II

Doosan DNM 400 II

Set up for high volume production, the DNM 400 is a highly productive and accurate machining centre.

  • 760mm x 400mm working area
  • High power Direct Drive 18.5KW 12000RPM spindle
  • Quick change 30 STATION ATC

Doosan Lynx 300M

Doosan Lynx 300M

With a built in tooling setting probe and parts catcher, the Lynx 300M is a flexible and versatile machine. Along with the built in bar-feed, it can self-load bars up to 3” diameter. The 12 Station Servo-driven BMT55 Milling Turret allows large turning and milling tools to be used.

  • Max Turn 450mm diameter x 700mm long
  • 15KW Main Spindle 3500RPM
  • 5.5KW Milling Spindle 5000RPM

Doosan Lynx 220LM

Doosan Lynx 220LM

A high speed turning centre with a parts catcher, a built in bar-feed, and a bar capacity of 2” diameter. With a 12 station half-index BMT 45 milling turret, it allows various tool configurations to be used to help reduce set-up times.

  • Quick change collet system
  • 15KW Main Spindle 6000RPM
  • 3.7KW Milling Spindle 6000RPM

DOOSAN DNM 500 WITH 4TH AXIS

Doosan DNM 500

The DNM 500 is equipped with a 10” diameter 4th axis unit and an extended memory Fanuc data server. This allows complex parts to be milled complete in one operation.

  • 1020mm x 500mm working area
  • High power 18.5KW 12000RPM spindle
  • Quick change 30 station ATC

2 x DOOSAN LYNX 220 LSYC

Doosan LYNX 220 LSYC

The Lynx 220 LSYC is a sub-spindle turning centre with Y-axis milling capability. The short magazine barfeed with 65mm capacity and the parts conveyor allows for lights out machining. Fully programmable C-axis on both spindles allows complex parts to be produced with guaranteed alignment between the front and rear faces. With an 8” chuck on the main spindle and 5” on the sub-spindle, it allows for a wide and varied range of parts to be manufactured. It also comes equipped with the same 12 station half-index milling turret found on the 220LM.

  • 15KW MAIN SPINDLE 4500RPM
  • 5.5KW SUB SPINDLE 6000RPM
  • 3.7KW MILLING SPINDLE 6000RPM

Want a free no-obligation quote for your CNC project?

Our Process

The three stages of precision engineering

Planning

Planning is fundamental to the efficiency and accuracy of the finished component and this is where a detailed work plan will be drawn up. This is also when the job will be scheduled on its appropriate work centre. The materials and processes that are incorporated in our components come from an approved supplier list of companies, with documented quality procedures in place.



Manufacture

Only when the planning phase is complete will the job be released for production. This will take place on our latest CNC machinery using top-quality cutting tools.

Quality

All components are inspected both during manufacture and after post-processes have been completed. This is in accordance with the ISO 9001 standard. This ensures that only components that conform to the drawing standard are despatched to the customer.

About Us

Industry leaders in precision engineering

Located just east of Nottingham city centre, here at Doosan Precision Engineering we specialise in CNC Turning and CNC Milling services. Grown from a small, local business in 2010, throughout the years, although our team may have expanded, we still provide the same personalised care for each of our clients.

At Doosan we understand the needs and expectations of our clients and our reliable and professional team here at Doosan can help you achieve your business goals today.

Our Mission Statement

We are commited to providing the very best possible CNC solutions to every single one of our clients.

Here at Doosan, we’re specialists in one-hit machining. As an ISO 9001 accredited company, incorporated in 2010, we strive to achieve top quality products and on time delivery. We use the latest advanced CNC technology machinery and cutting tools. We are also able to offer Kanban and Stock Inventory delivery systems.

Contact Us

Do you have a project in mind?

Whether you are looking for complex Multi Axis components or simple machined parts, just use our quote form to send us as much information as you have and we’ll reply with our quotation. Preferred drawing formats are DXF or PDF and models in STEP or IGES.
